Honda REFLEX - Belt Case Air Cleaner

−
(1)
LEFT SIDE
LEFT SIDE
(2)
(3)
(1) bolts
(2) belt case air cleaner assembly
(5) element(3) element cover
(4) tab
(5)
(4)
109
Belt Case Air Cleaner
Servicing Your Honda
Saf ety PrecautionsRefer to on page . Remove the element cover (3) by
releasing the tab (4).
Remove the element (5).Remove the left floor skirt (page 88).
Remove the three bolts (1) and the belt
case air cleaner assembly (2).
Gently wash the element in clean, non-
flammable (high flash point) solvent
such as kerosene not gasoline. After
cleaning, gently squeeze out the
remaining solvent.
Avoid twisting or wringing the element.
This can tear the foam.
