110
Belt Case Air Cleaner
Servicing Your Honda
Do not apply oil to the element. The drive
belt may be damaged.
Inspect the element for cracks or tears
in the foam or seams. Replace the
element if it is damaged.
Allow the element to dry thoroughly
before installation.
Install the element.
Install the element cover.
Install the belt case air cleaner assembly.
Install the removed parts in reverse
order of removal.
6.
7.
8.
9.
10.
11.
