rearview
mirror
turn signal switch
front brake fluid reservoir
horn button
start button
engine stop
switch
rearview
mirror
headlight
dimmer switch
front brake
lever
throttle grip
ignition switchglove box
rear brake
lever
rear brake fluid reservoir
speedometer
tachometer
10
Component Locations
Instruments & Controls
