(1)
(2)
HI
LO
(3)
(1) headlight dimmer switch
(2) turn signal switch
(3) horn button
21
Turn Signal Switch
Headlight Dimmer Switch
Controls & Features
Instruments & Controls
Theturnsignalswitch( )isusedtosignal
a turn or a lane change. To operate, move
the switch all the way in the proper
direction and release it. The appropriate
turn signal lights will start blinking. To
cancel the light, push the switch in.
If your scooter is stopped with the ignition
switch ON and the engine stop switch
OFF, the headlight and taillight will
remain on, resulting in battery discharge.
The headlight dimmer switch ( ) is used
to change between the high and low beams
of the headlight. To operate, turn the
switch to HI for high beam, LO for low
beam.
1
2
04/10/19 10:40:33 31KSZ610_030
