(1)
(2)
(4)
UNDER SEAT
(3) rubber band (4) battery
(5) negative ( ) terminal lead
(6) positive ( ) terminal lead
(5)
(6)
(3)
UNDER SEAT
(1) clips (2) battery cover
139
Battery
Servicing Your Honda
The battery is located in the battery box
below the seat.
Release the rubber band ( ) securing
the battery ( ).
Disconnect the negative ( ) terminal
lead ( ) from the battery first, then
disconnect the positive ( ) terminal
lead ( ).
Pull the battery ( ) out of the battery
box.
Lift the seat (page ).
Remove the battery cover clips ( ),
then remove the battery cover ( ).
(cont’d)
1.
2.
3.
4.
5.
5
4
6
3
1
2
4
36
