Honda REFLEX - Page 182

MAIN FUSE
(1)
UNDER SEAT
(2)
(3)
(5)
(1) main fuse
(2) wire connector
(3) starter magnetic switch
(5) spare main fuse
(4)
(4) blown fuse
173
If a Fuse Blows
Taking Care of the Unexpected
Main Fuse Access: Disconnect the wire connector ( ) of
the starter magnetic switch ( ).
(cont’d)
Pull the fuse out. If the main fuse is
blown ( ), install the spare main fuse
().
Reconnect the wire connector.
Install the battery cover and close the
seat.
To access the main fuse ( ), lift the
seat (page ) and remove the battery
cover (page ).
3.
4.
2.
5.
6.
1
2
3
4
5
