Honda WT30X - CONTROLS & FEATURES

8
CONTROLS & FEATURES
COMPONENT & CONTROL LOCATIONS
<Example: WT20X>
AIR CLEANER
THROTTLE LEVER
CHOKE LEVER
FUEL VALVE LEVER
STARTER GRIP
WRENCH
OIL DRAIN PLUG
OIL FILLER CAP
PRIMING WATER FILLER CAP
FUEL TANK CAP
IGNITION SWITCH
MUFFLER
SUCTION PORT
STRAINER
PUMP DRAIN PLUGPUMP COVER KNOB
DISCHARGE PORT
