SERVICING YOUR PUMP
SPARK ARRESTER SERVICE (optional part)
Your engine is not factory-equipped with a spark arrester. In some areas, it is
illegal to operate an engine without a spark arrester. Check local laws and
regulations. A spark arrester is available from authorized Honda servicing
dealers.
The spark arrester must be serviced every 100 hours to keep it functioning as
designed.
If the engine has been running, the muffler will be very hot. Allow the muffler to
cool before servicing the spark arrester.
1. Remove the 5 mm screws from the muffler protector, and remove the muffler
protector.
2. Remove the 4 mm screw from the spark arrester, and remove the spark
arrester from the muffler.
5 mm SCREW (4)
WT20X
4 mm SCREW
SPARK ARRESTER
MUFFLER
MUFFLER PROTECTOR
