29. TECHNICAL DATA
29.1. AS302P Meter
Current: IEC Ratings
MID/EN Rating
Ib - Imax = 5 - 100A, 10 - 100A, 20 - 100A
Imin - Itr(Imax) = 1.0 - 20(100)A, 0.5 10(100)A, 0.25 - 5(100)A
Frequency
Reference Voltage
Voltage Operating Range
50 Hz
230V a.c.
±20%
Short Circuit Current
Insulation Voltage
Impulse Withstand - Live to Neutral
- Live and Auxiliary Outputs
Short Circuit Current Withstand: 30 Imax
4000 Vac 1 min
12kV (40 ohm source)
6kV (40 ohm source)
Power Consumption
(At reference conditions and stated current)
Voltage Circuit
Current Circuit @ Basic Current
Max 0.8W
Average < 4W under normal operating conditions
0,02VA
Display
Viewing Angles
High Contrast, 2 Line Display
Vertical - 10˚ above, 40˚ below the horizontal
Horizontal - 30˚ either side of vertical
Meter Constant (pulsing LED output)
Pulse Width
4000 Pulses/kWh (kvarh)
Wavelength 640nm
5 ms
Auxiliary Relay
230V, 2A, a.c.
Product Design Life
Service Design Life
20 years
15 years
Temperature
Humidity
Specified Operational Range: -25 C to +55C
Limit Operating Range: -25 C to +70C
Storage Range: -25 C to +70C
Non - Condensing
Annual Mean 75% (95% for 30 days spread over one year)
Dimensions
125mm (H) x 130mm (W) x 65mm (D)
Accuracy Class kWh
EC Directive 2014/22/EC (MID) - Class A or Class B. (EN 504703)
IEC 62053-21, Class 1 or Class 2
Case
BS 7856:2013
IP53 to IEC 60529:1989
Terminals Main
8.2mm Diameter Bore, 2 x M6 Combi Pinch Screws
(Screw Material - Steel, Coated with Zinc Chromate)
Max Torque 2.8 N m
