62 AS302P Single Phase Smart Meter
____________________________________________________________________
© Honeywell - M450 001 1D - 23.05.2019
Level 1
Level 2
Level 3
Level 4
Description
Display Format
Credit
Mode
Prepay
Mode
Scroll
Mode
Engineering Mode
ZigBee Commissioning
Join
Comms Status
Leave
Only visible if terminal cover is open
ZigBee Info
Status
Network Info
Channel
Node ID
PAN ID
XPAN ID
EUID
Signal
ALCS 1
State
Shows ALCS State
✓
✓
Test
Long Press on SELECT Button changes State
of ALCS for 5 minutes
✓
✓
ALCS 2
State
Shows ALCS State
✓
✓
Test
Long Press on SELECT Button changes State
of ALCS for 5 minutes
✓
✓
ALCS 3
State
Shows ALCS State
✓
✓
Test
Long Press on SELECT Button changes State
of ALCS for 5 minutes
✓
✓
ALCS 4
State
Shows ALCS State
✓
✓
Test
Long Press on SELECT Button changes State
of ALCS for 5 minutes
✓
✓
ALCS 5
State
Shows ALCS State
✓
✓
Test
Long Press on SELECT Button changes State
of ALCS for 5 minutes
✓
✓
LED
State
State Change Active/Reactive or
Reactive/Active
✓
✓
