CLIF-CBUSLC INTERFACE – INSTALLATION & COMMISSIONING INSTRUCTIONS
3 EN1Z-1026GE51 R0417
SPECIFICATIONS
Table 3. CLIF-CBUSLC specifications
Power supply
19 … 29 VAC, 50/60 Hz or
20 … 30 VDC
Power consumption
typically dc: 5 W; max. 6 W
typically ac: 9 VA; max. 11 VA
Current consumption
typically dc: 210 mA; max. 240 mA
typically ac: 370 mA; max. 410 mA
Ambient temperature
0 … 40 °C (wall-mounting)
Storage temperature
-20 … +70 °C
Humidity
5 … 95% r.h. non-condensing
Dimensions
See Fig. 12 and Fig. 13.
Degree of protection
IP20 (mounted on walls, with two accessory MVC-80-AC1 covers)
Fire class
V0
Weight
0.6 kg (excl. packaging)
SYSTEM OVERVIEW
Overview of Hardware
Table 4. Overview of hardware
feature description
max.
cable
length
no.
bus
interfaces
RS485-1, isolated, C-Bus communication 1200 m 1
Ethernet Interface
e-mail communication, browser access 100 m 1
SUSI IP communication 100 m 1
USB 2.0 Device Interface (as Network Interface) 3 m 1
USB 2.0 Host Interface (max. 500 mA) 3 m 1
LEDs
power LED (green) -- 1
status LED (red, controllable by firmware) -- 1
LED L1 (yellow) unused -- 1
LED L2 (yellow) indicating that a SUSI client (ARENA
AX
, COACH
AX
or ARENA 3.0) is connected -- 1
bus status LEDs (for isolated RS485-1 interface) -- 2
