Honeywell Chronotherm III User Guide

REMOVING THE THERMOSTAT
1 Loosen the two captive screws at
2 Pull the thermostat out
the bottom
cornerg of the case.
from the bottom.
3 Lift the thermostat up and off the
base.
REPLACING THE THERMOSTAT
2 Swing down and press
1 Hang the thermostat on the tabs
on lower edge until
ther-
at the top of the base. mostat snaps in place.
27
3 Tighten the captive screws.
28

Honeywell Chronotherm III Specifications

General

Operating Modes	Heat, Cool, Auto, Off
Programming	7-day programmable
Stages	1 Heat/1 Cool
Type	Programmable
Voltage	24VAC
Display	Digital
Programmable Periods	4 per day
Backup Battery	AA alkaline batteries (2)
Temperature Range	40°F to 90°F (Heating)
