Honeywell CL30XC Service Manual

CONFIDENTIAL
Website: http://www.honeywellaircoolers.com
17
4.2 Wiring Color Description
Power Cord:
(1) White Live on main PCB
(2) Black Neutral on main PCB
(3) Green Earth (Ground)
Main Motor:
(1) White High speed on main PCB
(2) Yellow Medium speed on main PCB
(3) Blue Low speed on main PCB
(4) Black Neutral on main PCB
(5) Red to capacitor by end-closed connector
(6) Brown to capacitor by end-closed connector
(7) Green + Yellow Earth (Ground)
Water Pump:
(1) Black on main PCB (plug-in type)
(2) White on main PCB (plug-in type)
Swing Motor:
(1) Yellow on main PCB
(2) Yellow on main PCB

Honeywell CL30XC Specifications

General

Noise level	- dB
Product color	Silver
Package depth	395 mm
Package width	502 mm
Package height	885 mm
Package weight	13800 g

Weight and Dimensions

Depth	352 mm
Width	458 mm
Height	856 mm
Weight	11300 g
