Honeywell CL30XC Service Manual

CONFIDENTIAL
Website: http://www.honeywellaircoolers.com
3
1. PREFACE
This manual is designed to provide you with important service information. Be sure to read the
safety precautions prior to servicing the unit.
1.1 Safety Precautions
1 When servicing, set the POWER of the CONTROL PANEL to OFF and unplug the power
cord.
2 Observe the original lead dress. If a short circuit is found, replace all parts which have been
overheated or damaged by the short circuit.
3 After servicing, make an insulation resistance test to prevent the customer‟s exposure to
shock hazards.
1.2 Insulation Resistance Test
1 Unplug the power cord and connect a jumper between 2 pins (black & white).
2 The grounding conductor (green or green & yellow) is to be open.
3 Measure the resistance value with an ohm meter between the jumper lead and each exposed
metallic part on the equipment at all MODES (except POWER OFF).
4 The value should be over 1 MΩ.
1.3 Specifications
MODELS
ITEMS
CL30XC
CHL30XC
Power Supply
1Ø , 220-240V, 50Hz
Input (W)
252W
2250W
Running Current (A)
1.15A
10.23A
Fan Type
Blower
Fan Speeds
4
3
Fan Motor HP
1/6
Operation Control
Control Panel with Remote Control
Relative Humidity
Control
Adjustable
Air Direction Control
Vertical Louver (Right & Left) - Auto
Horizontal Louver (Up & Down) - Manual
Timer Control
0.5 to 8 hours
Protector
Fan Motor Internal Thermal Protector
Water Pump Internal Thermal Protector
Filter
Honeycomb media (427mm x 330mm x 50mm) & Carbon Filter
Power Cord
1.8m (3 wire with grounding)
Water Fill System
Manual (from side panel or detachable water tank)
Drain System
Detachable water tank or manual drain plug
Water Tank Capacity
8 US Gallon / 30 L
Net Weight
24.6 lbs / 11.2 kg
26.8 lbs / 12.2 kg
Outer Dimension
(W x D x H)
18.0‟‟ x 13.9‟‟ x 33.7‟‟
458 mm x 352 mm x 856 mm
18.0‟‟ x 13.9‟‟ x 33.7‟‟
458 mm x 352 mm x 856 mm

Honeywell CL30XC Specifications

General

Noise level	- dB
Product color	Silver
Package depth	395 mm
Package width	502 mm
Package height	885 mm
Package weight	13800 g

Weight and Dimensions

Depth	352 mm
Width	458 mm
Height	856 mm
Weight	11300 g
