Honeywell CL30XC Service Manual

CONFIDENTIAL
Website: http://www.honeywellaircoolers.com
21
6. REPLACEMENT PARTS LIST
No.
Drawing
Name
Qty
1
ACP30A-01-01
front panel
1
2
ACP30A-01-02
fume cover
1
3
ACP30A-01-03
front decoration panel
1
4
ACP30A-01-04-01
horizontal louver 1
1
5
ACP30A-01-04-02
horizontal louver 2
1
6
ACP30A-01-04-03
horizontal louver 3
1
7
ACP30A-01-04-04
horizontal louver 4
1
8
ACP30A-01-04-05
horizontal louver 5
1
9
ACP30A-01-04-06
horizontal louver 6
1
10
ACP30A-01-04-07
horizontal louver 7
1
11
ACP30A-01-04-08
horizontal louver 8
1
12
ACP30A-01-04-09
horizontal louver link (left)
1
13
ACP30A-01-04-10
horizontal louver link (middle)
1
14
ACP30A-01-04-11
horizontal louver link (right)
1
15
ACP30A-01-04-12
rubber cap for horizontal louver
16
16
ACP30A-01-05
RC receptor cover
1
17
ACP30A-02-01-01
Top cover
1
18
ACP30A-02-01-02
wiring holder A
4
19
ACP30A-02-01-03
top cover screw base
3
20
ACP30A-02-02
ice compartment cover
1
21
ACP30A-21-16
PCB wiring assembly
1
22
ACP30A-02-03-00B
IMD control panel
1
23
ACP30A-02-04-01
water flow regulator
1
24
ACP30A-02-04-02
water flow regulator knob
1
25
ACP30A-02-04-03
water flow regulator tube
2
26
ACP30A-03-01
left panel
1
27
ACP30A-03-02
latch
2
28
ACP30A-03-03
latch link
2
29
ACP30A-03-04
Long pin
2
30
ACP30A-03-05
Short pin
4
31
ACP30A-04-01
right panel
1
32
ACP30A-04-02
water fill door
1
33
ACP30A-06-01
blower housing base
1
34
ACP30A-06-02
vertical louver link
1
35
ACP30A-06-03
wind guiding lever cover
1
36
ACP30A-06-04
vertical louver 1
2
37
ACP30A-06-05
vertical louver 2
2
38
ACP30A-06-06
vertical louver 3
2
39
ACP30A-06-07
vertical louver 4
2
40
ACP30A-06-08
vertical louver 5
1
41
ACP30A-06-09
Blower wheel
1
42
ACP30A-06-10
synchronous motor
1
43
ACP30A-06-11
synchronous motor cover
1
44
ACP30A-07-01
Blower housing
1
45
ACP30A-07-02
Wiring box cover
1
46
ACP30A-07-03
water hose holder
1
47
ACP30A-08
back panel
1
48
ACP30A-09-01
honeycomb guard
1

Honeywell CL30XC Specifications

General

Noise level	- dB
Product color	Silver
Package depth	395 mm
Package width	502 mm
Package height	885 mm
Package weight	13800 g

Weight and Dimensions

Depth	352 mm
Width	458 mm
Height	856 mm
Weight	11300 g
