Honeywell CL30XC Service Manual

CONFIDENTIAL
Website: http://www.honeywellaircoolers.com
22
49
ACP30A-09-02
honeycomb holder
2
50
ACP30A-09-03
Honeycomb
1
51
ACP30A-09-04
Carbon filter
1
52
ACP30A-11-01
Base
1
53
ACP30A-11-02-01
Pump arm
1
54
ACP30A-11-02-02
pump lever shaft
1
55
ACP30A-11-02-03
wire holder B
1
56
ACP30A-11-02-04
wire holder C
1
59
ACP30A-11-03-03
pump arm spring
1
62
ACP30A-11-03-06
pump arm spring shaft
1
63
ACP30A-11-05-01
Pump cover
1
64
ACP30A-11-07
sponge washer
1
65
ACP30A-12-01-00
Tank assembly
1
66
ACP30A-21-27
Wire tie
1
67
ACP30A-12-02-05
Tank plug
1
70
ACP30A-12-03
front caster
2
71
ACP30A-12-04
rear caster
2
72
ACP30A-13-01
RC front cover
1
73
ACP30A-13-02
RC back cover
1
74
ACP30A-13-05
RC battery cover
1
75
ACP30A-13-06
cathode
1
76
ACP30A-13-07
anode
1
77
ACP30A-13-08
Connector
1
78
ACP30A-13-09
AAA battery
2
79
ACP30A-55-05
Pump
1
80
ACP30A-55-03
Motor
1
81
ACP30A-21-12
RC PCB
1
82
ACP30A-21-12-02
PCB support bracket
1
83
ACP30A-21-13A
PVC control panel
1
88
ACP30A-01-06
RC receptor clip
1
89
ACP30A-21-22
cut off switch
1
90
ACP30A-21-07
Low water level alarm
1
91
ACP30A-11-04
cut off switch adaptor
1
92
ACP30A-54-04
Ionizer
1

Honeywell CL30XC Specifications

General

Noise level	- dB
Product color	Silver
Package depth	395 mm
Package width	502 mm
Package height	885 mm
Package weight	13800 g

Weight and Dimensions

Depth	352 mm
Width	458 mm
Height	856 mm
Weight	11300 g
