Honeywell CL30XC Service Manual

CONFIDENTIAL
Website: http://www.honeywellaircoolers.com
8
Remote Control Operation: (CL30XC)
Power: On / Off
Speed: Low / Medium / High
Cool / Fan: Controls cooling or fan option
Swing / IONIZER: Controls the motion of the louvers & turns ON/OFF the
Ionizer function.
Timer: Controls timer function for automatic shut off
Sleep: Turns on the sleep mode, to vary the fan speed
randomly.
Remote Control Operation: (CHL30XC)
Power: On / Off
Speed: Low / Medium / High
Cool / Fan: Controls cooling or fan option
Swing / IONIZER: Controls the motion of the louvers & turns ON/OFF the
Ionizer function.
Heat: Turn ON/OFF of the heating function.
NOTE:
 Please open the battery compartment at the back of the remote control and insert two new
AAA dry cell batteries.
 Care must be taken to insert the batteries according to the correct polarity (+ / –) markings
shown inside the battery compartment.
 Always point the remote control signal transmitter towards the unit when operating.
 Make sure that the signal path is not obstructed.
 Remove the batteries if the unit is not going to be used for an extended period of time.
 Do not drop the remote control.
Fill Water:
Warning: Unplug from power when refilling.
Open the Water Fill Door located below the Remote Control Holder on the unit. The water tank of
the unit holds up to 30 litres of water.
Water level display window is located on the front of the unit. Refill the water tank when water
level is low. Do not fill water above the Max water level mark. Check water level in the tank before
running the ''COOL'' function. Please be sure water in the tank is always above minimum water

Honeywell CL30XC Specifications

General

Noise level	- dB
Product color	Silver
Package depth	395 mm
Package width	502 mm
Package height	885 mm
Package weight	13800 g

Weight and Dimensions

Depth	352 mm
Width	458 mm
Height	856 mm
Weight	11300 g
