System Installation Guide
22
69-2688—11 I/O-CHTSTAT03
Replacing system components
To remove accessories from a thermostat
At the thermostat
1 Press MENU and scroll down to press INSTALLER OPTIONS. Enter the date
code (password) when prompted. The date code is printed on the back of the
thermostat; or press MENU > EQUIPMENT STATUS to find the date code.
2 After you enter the password, scroll down to select WIRELESS DEVICE MANAGER.
3 Press REMOVE DEVICE, then select the device you want to remove.
Specifications & replacement parts
Operating Ambient Temperature
Thermostat: 32 to 120° F (0 to 48.9° C)
Portable Comfort Control: 32 to 120° F (0 to 48.9° C)
Wireless Outdoor Sensor: -40 to 140° F (-40 to 60° C)
Wireless Indoor Sensor: 0 to 120° F (-17.8 to 48.9° C)
– For Optimal Battery Life: 35 to 114° F (1.7 to 45.6° C)
RedLINK Internet Gateway: 32 to 120° F (0 to 48.9° C)
Operating Relative Humidity
Thermostat: 5% to 90% (non-condensing)
Portable Comfort Control: 5% to 90% (non-condensing)
Wireless Outdoor Sensor: 0% to 100% (condensing)
Wireless Indoor Sensor: 5% to 90% (non-condensing)
RedLINK Internet Gateway: 5% to 95% (non-condensing)
Physical Dimensions (height, width, depth)
Thermostat: 3-7/8 x 6-13/16 x 1-7/16 inches (99 x 173 mm x 36 mm)
Wireless Outdoor Sensor: 5 x 3-1/2 x 1-11/16 inches (127 x 89 x 43 mm)
Wireless Indoor Sensor: 2-7/8 x 1-7/8 x 15/16 inches (74 x 48 x 24 mm)
Portable Comfort Control: 6-1/4 x 3-1/8 x 1-5/8 inches (158 x 80 x 38 mm)
RedLINK Internet Gateway: 6 x 4-7/8 x 2-1/2 inches (152 x 124 x 64 mm)
Electrical Ratings
18 to 30 VAC
Accessories & Replacement Parts
Item Honeywell Part Number
RedLINK Internet Gateway THM6000R1002
Entry/Exit Remote REM1000R1003
Vent Boost Remote HVC20A1000
Portable Comfort Control REM5000R1001
Wireless Outdoor Sensor C7089R1013
Wireless Indoor Sensor C7189R1004
Cover Plate (covers marks left by old thermostats) 50028399-001
Battery Pack (For demo use only) THP1000A1007
