Chapter 7. PARAMETER SETUP
7-2 Parameter Setting List
NOTE “PVU (PV1)”, “PVU (PV2) and “SPU” used in the “Factory Default Settings” and
“User Settings” columns in the lists on the following pages have the following
meaning.
PVU (PV1) : When the PV1 range type (setup data setting
C01
) is a thermocouple or
resistance temperature detector, the PV1 decimal point position (setup data
setting
C03
) causes the decimal point position to change.
When the PV range type is linear, the PV1 linear decimal point position
(setup data setting
C04
) causes the decimal point position to change.
For example, in a decimal point position of 1,
–19999 PVU (PV1) becomes –19999.9 and +20000 PVU (PV1) becomes
+2000.0.
PVU (PV2) :Like PVU (PV1), a PV2 range type (setup data setting
C11
), a PV2 deci-
mal point position (setup data setting
C13
) and a PV2 linear decimal point
position (setup data setting
C14
) causes the decimal point position to
change.
SPU : The SPU decimal point position (setup data setting
C65
) causes the deci-
mal point position to change.
For example a decimal point position of 2,
–19999 SPU becomes –199.99 and +20000 SPU becomes +200.00.
7-4
