- 6 -
MASK CONDITION (DT8360ACM-SN only)
Normal Anti-Mask Condition
The sensor uses Active Infrared (AIR) technology to detect
masking. The sensor signals a mask condition when a
variety of materials and reflective objects are placed within
50mm (2 inches) in front of the sensor. To avoid false
mask alarms, follow the mounting guidelines shown in
Step 1.
Clearing an Anti-Mask Condition
When most masking materials or objects are removed, the
anti-mask condition will be cleared after several seconds.
When the cause of the anti-mask condition is any type of
spray or paint coating applied to the window, the window
must be replaced before the anti-mask condition can be
cleared. After replacing the window, perform a walk-test on
the sensor.
TROUBLESHOOTING
Mask
1
2
3
*TROUBLE CONDITIONS:
1. Mask condition: Sensor IR window is blocked or
masked.
2. Low Voltage: The sensor is disabled. Note: If voltage
drops below 5V, both Alarm and Trouble relays open.
3. Self-Test Failure conditions:
• Microwave supervision failure: The sensor is
operating in PIR mode only.
• PIR self-test failure: The sensor is disabled.
• Temperature compensation failure: The
temperature compensation is disabled.
Depending on the Trouble condition, take the following
corrective actions:
• Verify the sensor is not blocked or masked.
• Verify the power supply is sufficient (at least 9V at the
sensor).
• Cycle power to the sensor.
• Walk test the sensor.
If the Trouble condition does not clear, replace the sensor.
SPECIFICATIONS
Range: Ø 21m max.
Mounting Height: 2.4m – 8m
IP Rating: IP30
Power: 9.0 - 15 VDC; 6 mA standby (V-Plex@ version),
20 mA max., 12 VDC;
AC Ripple: 3 V peak-to-peak at nominal 12 VDC
Tampers: Cover & Wall; (NC with cover installed) Form A;
30 mA, 25 VDC; Magnetic field
Microwave Frequencies Range: 10.5 – 10.55GHz
RFI Immunity: 20V/m, 80MHz-1GHz
PIR White Light Immunity: 6,500 Lux typical
Fluorescent light filter: 50 Hz / 60 Hz
Operating Temperature: -10℃ - 55℃
Relative Humidity: 5 to 95%; non-condensing
Temperature Compensation: Advanced Dual Slope
Dimensions: 14.8 cm x 16.2 cm x 4.7 cm
Notes
• Install the devices and system in the isolated and
dedicated network system with physical security.
• Ensure only the authorized technician may access
and operate the device.
• Ensure to have regular system maintenance and
check the device functionalities work normally.
• Access
https://www.honeywell.com/contact-
us/vulnerability-reporting to report any vulnerability.
