3.2.2. Setup Sealing Button
Figure 3. Communication Sealing
The setup sealing button is dedicated switch for locking in the system configuration settings.
The settings are done using the front panel display and navigation buttons and all the system
related setup shall be locked prior to the meter operation.
3.2.3. Protective Enclosures
The E-Mon Class 6000 meter comes with a metallic and plastic enclosure for operational
safety and miscellaneous protection from external influence. The protective enclosure is
designed for durability and robustness and allows the meter to operate outdoors as well as
Indoor. The enclosure protects the meter body and helps in operational continuity in adverse
environmental conditions.
Note
• Practice caution and avoid touching the panel when it is powered on.
• Ensure that the setup is sealed using the red sealable button after performing the
connection and configuration.
