Honeywell E-Mon Class 6200 User Manual

Front Panel Display & Navigation
E-Mon® Series - Global User Manual
54-000-01-ENG01-0121
Page | 49
c. Current –Toggle to the current option in maximum menu by pressing Down arrow to
check the values. Long press SET to go back to the main screen.
▪ Displays cumulative () maximum current (I) and per phase (L1, L2, L3) maximum
current.
d. Active power (|+A|+|-A|) maximum for the power system. Toggle to the Monitoring
menu and check the values by pressing Down arrow to check the values.
▪ Provides the cumulative () maximum total power reading (|+A|+|-A|).
e. Net Active power (|+A|-|-A|) maximum for the power system. Scroll to the maximum
active net power option in the Monitoring menu by pressing Down button to check the
values.
▪ Provides the cumulative () maximum net total power reading (|+A|+|-A|).
