Enhanced Micro TDC 3000 User’s Manual 6-12 9/95
6.5
Table 6-4 — Parts List (Continued)
PART NUMBER DESCRIPTION
* 51107595-100 WINCHESTER PS Power Supply
* 51196243-100 445 MEGABYTE DRIVE History Module Hard Disk Drive
* 51196680-100 512 MEGABYTE DRIVE History Module Hard Disk Drive
51304395-100 WREN INTF CABLE Signal Cable from SPC I/O to WREN III
51109181-010 LCN CABLE SET Standard cable set (for LCN Upgrade)
51401551-XXX K2LCN BOARD High Performance Processor w/Memory
* 80360206-001 CLI BOARD Computer Interface Board
* 51196701-100 CLI/A - EMC Computer Interface Board (RS449)
80360209-001 CLI I/O ADAPTER CLI Paddleboard (RS232D)
80360230-001 CLI I/O ADAPTER CLI Paddleboard (RS449)
51401669-100 FAN ASSEMBLY Micro Fan Module Assembly
* ORU Level Replacement Item
Table 6-5— Parts List, LCN Upgrade for 3, 4, 5, or 6 Nodes
PART NUMBER DESCRIPTION
51109806-002 LCN CABLE SET (RG59) Two Meter Cable Set
30732052-001 BNC PLUG TERMINATOR Termination Module
51107403-100 LOCAL CNTL NTWK TRNSCV Local Control Network Transceiver
51190728-105 CONN BNC T Connector
Spare parts for the Multinode Module and its components (fan, power supply, boards, etc.)
are listed in the 8-Node Multinode Module Service manual in the Implementation/8-Node
Enhanced Micro TDC 3000 binder. Spare parts for the Five/Ten-Slot Module and its
components (fan, power supply, boards, etc.) are listed in the Five/Ten-Slot Module
Service manual in the LCN Service - 2 binder.
