Enhanced Micro TDC 3000 User’s Manual 3-2 9/95
3.1.1
53287
7
8
9
10
6 5
4
3
2
1
Power
Fan Alarm LED
LO-NOM-HI
Reset
Error
DC B
Power OK
ON
A
Fan Assembly
Nodes-
Yellow or
Green LEDs
Alphanumeric
Red LEDs Switch
Jumper
Supply
Green LEDs
Status Displays
Figure 3-1 — Typical 4-Node Tower Electronics—Front View
