Enhanced Micro TDC 3000 User’s Manual 4-17 9/95
4.4.3
Chart 4-1 — APM Box Point I/O Chart (n = 1 through 40) (continued)
Double-Sided Cabinet, Redundant APM
IOP Number IOMFILEA File No. IOMCARDA Card No. IOMTYPE(n)
Card Type
1 1 6 HLAI
217AO
318DI
419DO
5 1 10 None
6 2 1 None
7 2 2 None
8 2 3 None
9 2 4 None
10 2 5 None
11 2 6 None
12 2 7 None
13 2 8 None
14 2 9 None
15 2 10 None
16 2 11 None
17 2 12 None
18 2 13 None
19 2 14 None
20 2 15 None
21 3 1 None
22 3 2 None
23 3 3 None
24 3 4 None
25 3 5 None
26 3 6 None
27 3 7 None
28 3 8 None
29 3 9 None
30 3 10 None
31 3 11 None
32 3 12 None
33 3 13 None
34 3 14 None
35 3 15 None
36 4 1 None
37 4 2 None
38 4 3 None
39 4 4 None
40 4 5 None
