Enhanced Micro TDC 3000 User’s Manual 4-24 9/95
4.8.2
Module Summary Display Configuration
Line 1: HEADER
Title: MICRO TDC 3000 PROGRAMS
Line 2: BLANK
Line 3: MODULE
Module ID: APM_SEQ
Lines 4-21: BLANK
Page 3: Screen 0
Disp. Type: MODGROUP
Group Number: 1
Annunciator Display Configuration
Box number: 1, Number of points: 2
Box title: UTDC 3000
Point names: AM_REG, APM_REG
Related Display: Screen 0, Type ALARMSUM
Associated Display: Screen 0, Type GROUP
Group No.: 1, Slot/IOM No.: 0
Help Display: Screen 0, Type PMSTAT
Process NTWK No.: 1, Box/Node: 3
Process Journals
No. 1, Journal Name: ALARMS
Journal Title: MICRO TDC3000 ALARMS
Journal type: ALARM, Invoc. type: DEMAND
Ptr ID: 1, Time Span: 72,
No. Units: 10, Units: 1-10
No. 2, Journal Name: MESSAGES
Journal Title: MICRO TDC3000 MESSAGES
Journal type: OPERMSG, Invoc. type: DEMAND
Ptr ID: 1, Time Span: 72,
No. Units: 10, Units: 1-10
No. 3, Journal Name: CHANGES
Journal Title: MICRO TDC3000 OPERATIONS
Journal type: OPERCHG, Invoc. type: DEMAND
Ptr ID: 1, Time Span: 72,
No. Units: 10, Units: 1-10
System Journals
No. 1, Journal Name: SYSTEM1
Journal Title: MICRO TDC3000 SYS STATUS
Journal type: SYSSTAT, Invoc. type: DEMAND
Ptr ID: 1, Time Span: 72,
No. 2, Journal Name: SYSTEM2
Journal Title: MICRO TDC3000 SYS ERRORS
Journal type: SYSERR, Invoc. type: DEMAND
Ptr ID: 1, Time Span: 72,
No. 3, Journal Name: SYSTEM3
Journal Title: MICRO TDC3000 SYS MAINTS
Journal type: SYSMAINT, Invoc. type: DEMAND
Ptr ID: 1, Time Span: 72,
Real-Time Journal Assignment Configuration
Journal type:
Process Alarms: Initially active? YES
Oper. Process Chgs.: Initially active? YES
Oper. Messages: Initially active? YES
Syst. Status Changes: Initially active? YES
System Error Msgs.: Initially active? YES
System Maint. Msgs.: Initially active? YES
Printer ID (all journal types): 1
Overview Configuration
Group numbers: 1, No. of fields: 1
Field definition: Index 01
Field title: MICRO TDC3000
Top left element: 1,
Width 6, Height 4
Related Display 001 Definition:
Screen number: 0
Display type: NULL
Associated Display Definition:
Screen number: 0
Display type: NULL
Help Display Definition:
Screen number: 0
Display type: NULL
Area Trend Display Configuration
Trend title: MICRO TDC3000 AREA TREND
Trend timebase: 8 HOURS
Axis set definition: not configured
LCN Node Annunciation Policy
Annunciation policy
Address annunciated?:
Addresses 01 through 08: YES
Addresses 09 through 64: NO
The Following Not Configured:
Batch Summary
Standard Log
Printed Trend
SOE Journal Assignment
