Honeywell Enhanced Micro TDC 3000 User Manual

Enhanced Micro TDC 3000 User’s Manual 5-2 9/95
5.1.1
54121
ENGINEERING MAIN MENU
DD MM YY H:M:S
Support Functions and Utility Programs
CONSOLE STATUS
SYSTEM STATUSSYSTEM MENU
SMCC/
MAINTENANCE
COMMAND
PROCESSOR
SUPPORT
UTILITIES
R 500 (C) HONEYWELL INC., 1995
UNIT NAMES
AREA NAMES
CONSOLE NAMES
SYSTEM WIDE VALUES
VOLUME CONFIGURATION
LCN NODES
PICTURE EDITOR
FREE FORMAT LOGS
BUTTON CONFIGURATION
HM HISTORY GROUPS
DOCUMENTATION TOOL
AREA DATA BASE
HIWAY GATEWAY
LOGIC BLOCKS
APPLICATION MODULE
COMPUTING MODULE
NETWORK INTERFACE
MODULE
BUILDER COMMANDS
The Engineering Main Menui s shown above. This display is available when the Universal
Personality is loaded on a station.
54122
DD MM YY 14:54:36 2
CONSOLE STATUS AND ASSIGNMENT
SELECT FUNCTION
CONSOLE 1 - CONSOLE 1
LOCAL STA ADB:14 28Oct 16:34:Ø7:160
STN NODE TYPE
1
2
*
1
2
UNVL
UNVL
STATUS
OK
OK
PERIPHS
PRTRS DRIVES PENS ACCESS MAINT
OK
OK
1, 2 ENGR
OPR
AREA
:BOILER2
:BOILER2
11
2
ENB AUTO
LOAD/DMP
ACCESS
CHG
LOAD/
DUMP
SHUT
DOWN
PERIPH
STATUS
MAINT
INFO
PRTR
ASSIGN
AREA
CHG
STATUS
DETAIL
UNIT
DISPLAY
ENTER
The Console Status display is available in both the Operator Personality and the Universal
Personality. This is the first display to appear when a station is loaded.

Honeywell Enhanced Micro TDC 3000 Specifications

General

Brand	Honeywell
Model	Enhanced Micro TDC 3000
Category	Controller
Language	English
