Fire Alarm Control Panel IQ8Control C / M
FB 798951.10.GB0 / 04.15 129
18 esserbus
®
transponder
esserbus
®
transponders are input/output modules for extending the control panel inputs/outputs. It is possible to
install up to 32 esserbus
®
transponders in separate detector zones (separated by zone isolators). Mixing the
operation of fire detectors and esserbus
®
transponders is not permissible within one detector zone.
The esserbus
®
transponders is installed either at special fitting locations or with the top hat rail mounting kit
(Part No. 788652) in the Fire Alarm Control Panel, or at decentralised level at any location in a special plastic
housing (e.g. Part No. 788600).
For additional information refer to the Product catalogue fire and documentation of the esserbus
®
transponder.
For esserbus
®
PLus loops with a loop voltage of 42 V it is required to connect the appropriate
transponders or devices with the Part No. 80xxxx (see Chapter 5.1.2).
