Fire Alarm Control Panel IQ8Control C / M
FB 798951.10.GB0 / 04.15 33
6.1.1 Specification Power supply module (Part No. 802426)
Main voltage : 230 V AC (+10% / -15%)
Rated current : 0,7 A
Rated frequency : 50 Hz to 60 Hz
Output voltage : 12 V DC
Current for ext. devices : max. 2 A
Permissible current consumption with
2 x 24 Ah batteries and 72 hour
emergency power supply : max. 650 mA
Battery capacity : max. 2 x 12 V DC / 24 Ah (= 48 Ah)
Battery charge voltage : 13,65 V DC @ 25 °C
Ambient temperature : -5 °C to +45°C
Storage temperature : -5 °C to +50°C
Protection class : I according to DIN EN 60950
Compatibility : Part No. 802426 Index G or higher
The power supply module is suited for the FACP IQ8Control C/M
with the required Basic module (Part No. 772481/-82).
The required loop voltage (27,5 V or 42 V for esserbus
®
PLus)
must be selected on the power supply module with jumper BR4!
Undervoltage protection : 9,5 V DC
(with jumper BR2 switch-on / off)
For FACP IQ8Control C/M it is possible to use the power supply
module from hardware version Index G as a replacement module.
Pay attention to the settings on the power supply module of FACP
IQ8Control C/M and the Index of the hardware that is used!
Damage to the system!
Before connecting the alternating voltage (230V AC) read the
identification plate (sticker in and on the housing of FACP) . It is not
permitted to connect a voltage other than that shown on the
identification plate.
