7.1.7 Technical data essernet
®
micro module
essernet
®
micro module 62.5 k
(Part No. 784840 / 784840.10)
essernet
®
micro module 500 k
(Part No. 784841 / 784841.10)
Operating voltage : Internal via the power supply module,
+ 5 V DC
Internal via the power supply module,
+5 V DC
Current consumption approx. 150 mA @ 12 V DC
Emergency operation : yes
Connector : A single essernet
®
micro module may be connected per FACP on the appropriate
micro module slot on the Basic module.
Observe jumper X4 / X5!
Network devices : max. 16 max. 31
Transmission speed : up to 62.5 kBd up to 500 kBd
Required cable : Telephone cable
I-Y (ST) Y n x 2 x 0.8 mm,
Cable length max. 1000 m.
Other cable types such as paper-
wrapped cables, control lines (NYM) or
smaller cross-sections are not suitable.
IBM type 1 max. 1000 m
between two network devices
IBM type 2 (Earth cable) max. 1000 m
between two network devices
IBM type 6 (flexible) max. 200 m
between two network devices
The cable must be twisted and shielded.
The signal wires are protected against interference through connection of the
cable shielding.
Transmission : Token-Passing protocol similar to DIN 19245 - 1 (Profi BUS)
Topology : loop topology (wire-breakage und short circuit tolerance)
Compatibility : essernet
®
micro module 62.5 kBd (Part No. 784840)
Do not operate hardware with index up to B2 with hardware from index
B3 in a common panel.
