Honeywell Excel 10 W7752D - Step 5. Order Equipment

EXCEL 10 FCU CONTROLLER LNS PLUG-INS USER GUIDE
EN2B-0285GE51 R0909
24
Step 5. Order Equipment
After compiling a bill of materials through completion of the previous application steps, refer to Table 15 for ordering information.
Contact Honeywell for information about controllers and Excel 10 wall modules with no logo.
Table 15. Excel 10 FCU Controller ordering information
Part Number Product Description Comments
Excel 10 FCU Controllers
W7752D2007
230 Vac, FTT L
ONWORKS version w/ relay for
electrical reheat applications
W7752E2004
230 Vac, FTT L
ONWORKS version w/o relay
for electrical reheat applications
W7752F2002
115 Vac, FTT L
ONWORKS version version w/
relay for electrical reheat applications
W7752G2000
115 Vac, FTT L
ONWORKS version w/o relay
for electrical reheat applications
W7752J2003
100 Vac, FTT L
ONWORKS version w/o relay
for electrical reheat applications
W7754K1001
230 Vac, FTT L
ONWORKS version w/o releay
for electrical reheat applications; digital out-
put for low-voltage PWM control of solid-
state relay for high-current electric reheat
applications; one triac
W7754L1009
24 Vac, FTT L
ONWORKS version w/o releay
for electrical reheat applications; two triacs
W7754M1007
230 Vac, FTT L
ONWORKS version w/o releay
for electrical reheat applications
W7754N1004
230 Vac, FTT L
ONWORKS version w/o releay
for electrical reheat applications; two triacs
W7754P1000
230 Vac, FTT L
ONWORKS version w/ releay
for electrical reheat applications; four triacs
Excel 10 Wall Modules
T7460, T7560 See Excel 10 wall module literature for details.
Excel 10 Sensors
C7068A1007 (Europe) Air Temperature Sensor Return air
Echelon-Based Components and Parts
209541B FTT Termination Module Two required per LONWORKS segment.
205979A (US only) SLTA Connector Cable for LONWORKS bus Serial interface to wall module or controller.
Cabling
—
Serial Interface Cable, male DB-9 to female
DB-9 or female DB-25.
Obtain locally from any computer hardware vendor.
Honeywell (US)
AK3791 (one twisted pair)
AK3792 (two twisted pairs)
Belden (Europe)
9H2201504
L
ONWORKS (plenum): 14 to 20 AWG (2.0 to
0.5 mm
2
) twisted pair solid conductor, non-
shielded.
Level IV 140°F (60°C) rating
Honeywell (US)
AK3781 (one twisted pair)
AK3782 (two twisted pairs)
Belden (Europe)
9D220150
L
ONWORKS (non-plenum): 14 to 20 AWG (2.0
to 0.5 mm
2
) twisted pair solid conductor, non-
shielded.
Level IV 140°F (60°C) rating
Honeywell (US) AK3725
Inputs: 18 AWG (1.0 mm
2
) five wire cable
bundle.
Standard thermostat wire
Honeywell (US) AK3752
(typical or equivalent)
Outputs/Power: 14 to 18 AWG (2.0 to
1.0 mm
2
).
NEC Class 2 140°F (60°C) rating
Honeywell (US) AK3702
(typical or equivalent)
18 AWG (1.0 mm
2
) twisted pair. Non-plenum
Honeywell (US) AK3712
(typical or equivalent)
16 AWG (1.5 mm
2
) twisted pair. Non-plenum
Honeywell (US) AK3754
(typical or equivalent)
14 AWG (2.0 mm
2
) two conductor. Non-plenum
