Galaxy Dimension Installer Manual
2-12
Table 2-6. Zone Address Ranges
Zone Addressing with Onboard RIO Switch (Line 0 Switch)
The RIO switch (SW3, dipswitch 8) controls the ordering of the on-board RIO’s. This dipswitch must be set
before powering up the panel. Setting the switch to ON
sets the on-board RIO1 to operate on line 0 and
allows a RIO addressed as 1 to be connected to line 1, giving a total of 15 RIO’s on a GD-264 and
GD-520. The RIO switch only needs to be activated when the full compliment of RIO’s is required, or when
replacing a Galaxy 512 panel with a power supply/RIO already using address 1.
NOTE: The RIO switch is not functional on other variants. It defaults to the Switch off configuration.
Switch off (default)
When the switch is set to this mode, the onboard RIO’s configure to the following addresses:
Onboard RIO0 Zone address range: 1001-1008 Outputs: 1001-1004
Onboard RIO1 Zone address range: 1011-1018 Outputs: 1011-1014
Switch on
When the switch is set to this mode, the onboard RIO’s configure to the following addresses:
Onboard RIO0 Zone address range: 1001-1008 Outputs: 1011-1014
Onboard RIO1 Zone address range: 0011-0018 Outputs: 0011-0014
RIO Switch
Panel On-Board RIO Address Range Total
on-board
Zones
Max No of
External RIO's
(Line 1)
Valid External
RIO Addresses
(Line 1)
Total Zone
Addresses
(Switch ON)
GD-48 1001 - 1008, 1011 - 1018 16 4 2 - 5 48
GD-96
1001 - 1008, 1011 - 1018 (switch off) 16 4 2 - 5
96
1001 - 1008, 0011 - 0018 (switch on) 16 5 1 - 5
GD-264 1001 - 1008, 1011 - 1018 (switch off) 16 14 2 - 9, A - F
264
1001 - 1008, 0011 - 0018 (switch on) 16 15 1 - 9, A - F
GD-520
1001 - 1008, 1011 - 1018 (switch off) 16 14 2 - 9, A - F
520
1001 - 1008, 0011 - 0018 (switch on) 16 15 1 - 9, A - F
