Honeywell Galaxy Dimension GD-96 Installer Manual

1-1
Galaxy Dimension Installer Manual
INTRODUCTION
This manual gives full instructions required to install and program a Galaxy Dimension control panel and
associated peripherals.
Variants
The Galaxy Dimension is available in four variants: GD- 48, GD-96, GD-264 and GD-520. The differences
between each variant are shown in the following table:
Introduction
Table 1-1. Galaxy Dimension General Specification
Features GD-48 GD-96 GD-264 GD-520
Zones 16-48 16-96 16-264 16-520
Outputs (400mA) 8-24 8-48 8-132 8-260
Trigger Outputs on Flying Lead
(100mA)
66 6 6
PSU 2.5A 2.5A 2.5A 2.5A
RS485 Databuses 12 2 4
Telecom onboard Yes Yes Yes Yes
RS232 Interface for online PC RS232 RS232 RS232 RS232
Printer Interface RS232 RS232 RS232 RS232
Ethernet option Yes Yes Yes Yes
GPRS option 3rd Party 3rd Party 3rd Party 3rd Party
Groups 8163232
Keypads 8161632
Keyprox 37 724
Multi-user Yes Yes Yes Yes
DCM's with 2 x wiegand
interfaces
4161632
DCM Controlled doors
8323264
Bus mounted prox readers
(MAX)
4161632
Access control groups (user
templates)
50 50 100 100
Weekly Timer Schedules 19 35 67 67
Annual Holiday Schedules 16 32 32 32
Users 100 250 999 999
Links 64 128 256 256
Remote software update Yes Yes Yes Yes
Upload/Download Yes Yes Yes Yes
Remote service Yes Yes Yes Yes
Network downloader Yes Yes Yes Yes
Alarm monitoring Yes Yes Yes Yes
Graphics mimic Yes Yes Yes Yes
TouchCenter 12 2 4
Mimic panel Yes Yes Yes Yes
Wireless Ademco 5800 Ademco 5800 Ademco 5800 Ademco 5800
Audio Verification Channels 8163232
SMS Yes Yes Yes Yes

Honeywell Galaxy Dimension GD-96 Specifications

General

Brand	Honeywell
Model	Galaxy Dimension GD-96
Category	Control Panel
Language	English
