Master Progr
amming Level
Programming
Freeze Supervision
Pressing
1
for
Fr
eeze Supv
.
while viewing Edit Input Zone Scree
n #4 programs the F
ACP
to supervise the
devices connected to the selected zone for freeze condit
ions. Each press of the 1 key will toggle the display
between
Fr
eeze Supv
. Y
es
and
No
.
The factory default setting
is No Freeze Supervision.
INPUT ZONE #
1=FREEZE SUPV. NO
2=ACC MSG #
Edit Input Zone Screen #4
GF5
05
& GF510 Manual
—
P/N
53164
:B5
6/1
2/2018
53
52
54
Table of Contents
Table of Contents
5
Section 1: Product Description
12
Product Features
12
Specifications
13
Controls and Indicators
16
Digital Alarm Communicator/Transmitter
16
Components
17
Optional Modules and Accessories
17
Telephone Requirements and Warnings
18
1: Telephone Circuitry
18
2: Digital Communicator
18
3: Telephone Company Rights and Warnings
18
Section 2: Installation
19
Backbox Mounting
19
Operating Power
21
Input Circuits
22
Output Circuits
24
1: Notification Appliance Circuits
24
2: Special Application DC Power Output Connections
25
3: Relays - Programmable
26
4: Remote Synchronization Output
26
Power-Limited Wiring Requirements
27
Digital Communicator
28
Installation of Optional Modules
29
1: CAC-5X Class a Converter Module
29
Installation
29
Wiring Nacs and Idcs for Class a
29
2: 4XTMF Option Module
30
4XTMF Transmitter Module Installation
31
3: ANN-SEC Option Card
32
ANN-BUS Devices
33
Guidelines
33
1: ANN-BUS Wiring
33
Calculating Wiring Distance for ANN-BUS Modules
33
Wiring Configuration
34
Powering ANN-BUS Devices from Auxiliary Power Supply
36
2: ANN-BUS Device Addressing
36
3: GFANN-80 Remote Fire Annunciator
37
Specifications
37
Installation
37
Opening/Closing Annunciator
37
Mounting
37
Wiring GFANN-80 to FACP
38
4: GFANN-LED Annunciator Module
39
Specifications
39
Mounting/Installation
39
GFANN-LED Board Layout and Connection to FACP
40
5: GFANN-RLY Relay Module
40
Specifications
40
Mounting/Installation
41
GFANN-RLY Board Layout and Connection to FACP
42
Section 3: Programming
43
User Programming
43
Initial Power-Up
45
Programming Screens Description
45
Programming and Passwords
45
Master Programming Level
46
1=Input Zones
46
2: NAC (Notification Appliance Circuit)
56
Enabled
56
NAC Coding
56
Silence
58
Auto Silence
58
Silence Inhibited
58
3: Relays
59
4: System Setup
59
Timers
59
Banner
61
Time-Date
61
Trouble Reminder
62
Charger Disable
62
5: Option Modules
62
Ann-Bus
63
ANN-RLY Options Screen
64
ANN-SEC Enable
64
Onboard DACT
65
6: History
81
View Events
81
Erase History
82
7: Walktest
82
8: Clear Program
82
Printer/Pc
83
9: Password Change
83
Maintenance Programming Level
84
1: Input Zones - Enable/Disable
84
2=History
84
3=Walktest
85
4: Time-Date
85
Section 4: Operating Instructions
86
Panel Control Buttons
86
1: Acknowledge/Step
86
2: Alarm Silenced
86
3: Drill/Hold 2 Sec
86
4: Reset
86
LED Indicators
86
Normal Operation
86
Trouble Operation
87
Alarm Operation
87
Supervisory Operation
88
Process Monitor Operation
88
Hazard/Tornado Condition Operation
89
Medical Alert Condition Operation
89
Disable/Enable Operation
89
Waterflow Circuits Operation
89
Detector Functions
89
Time Functions: Real-Time Clock
90
Coded Operation
90
Presignal
90
Positive Alarm Sequence
90
Special System Timers
90
1: Silence Inhibit Timer
90
2: Autosilence Timer
91
3: Trouble Reminder
91
4: Waterflow Retard Timer
91
5: Alarm Verification (None or One Minute)
91
Walktest
91
Read Status
92
1=Input Zones
92
2=Nac 2
92
3: Relays
93
4: System Settings
93
5: Timers
93
6: Daylight Savings
93
7: History
93
8: Print
93
9: Ann-Bus
94
10: Central Station
94
11: Phone Line
94
12: Service Terminal
95
Section 5: Central Station Communications
96
Transmittal Priorities
96
Section 6: Local/Remote Site Upload/Download
98
Remote Download
98
Transferring a Program
98
1: Security Features
99
Section 7: Power Supply Calculations
100
Overview
100
Calculating the AC Branch Circuit
100
Calculating the System Current Draw
100
2: How to Use Table 7.3 on Page 101 to Calculate System Current Draw
100
Calculating the Battery Size
102
1: NFPA Battery Requirements
102
2: Selecting and Locating Batteries
102
Appendix A: Ademco Contact ID Format Event Code Descriptions
103
A.1: Transmission Format between DACT and Receiver
103
A.2: Ademco Contact ID Typical Printout
103
Appendix B: NFPA Standard-Specific Requirements
108
B.1: Central Station/Remote Station Transmitter: Connection to FACP Dry Contacts
113
Appendix C: FACP with Keltron
114
Appendix D: Wire Requirements
115
D.1: GF-505 NAC Wiring
115
D.2: GF-510 NAC Wiring
116
Appendix E: Default Programming
117
Index
118
GF505 & GF510 Fire Alarm Control Panel Operating Instructions
