Performance Series IP Camera Software Configuration Guide
74
H4W2PRV2/H4W4PRV2 Mini Dome Cameras
Table 8-5 H4W2PRV2/H4W4PRV2 Specifications
Camera
Image Sensor
H4W2PRV2: 1/2.7″ 2 megapixel progressive scan CMOS
H4W4PRV2: 1/3″ 4 megapixel progressive scan CMOS
Max. Effective Pixels (H×V)
H4W2PRV2: 1920×1080 (2 MP)
H4W4PRV2: 2688×1520 (4 MP)
Min. Illumination 0.1 lux @ F1.4 (Color)/0 lux @ F1.4 (B/W with IR LEDs on)
Lens MFZ, 2.7-12 mm @ F1.4
Horizontal Angle of View
H4W2PRV2: 93°-35°
H4W4PRV2: 86°-30°
Automatic Electronic Shutter 1/3 – 1/100000 s
S/N Ratio >50 dB
IR Range Up to 100 ft (30 m), depending on scene reflectance
Day/Night Auto(ICR)/Color/BW
BLC/WDR BLC/HLC/WDR (120 dB)
White Balance Auto/ Manual
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detection Up to 4 areas
Privacy Masking Up to 4 areas
Video
Compression H.264/H.264H/H.264B/MJPEG
Frame Rate
H4W2PRV2: 25/30 fps @ 1920 ×1080 (2 MP); 25/30fps @
1280×1024 (SXGA); 25/30fps @ 1280×960 (1.3 MP), 1280×720
(720p), 704×576/704×480 (D1), 352×288/352×240 (CIF)
H4W4PRV2: 20 fps @ 2688×1520(4 MP); 20 fps @ 2560 × 1440 (4 MP);
25/30 fps @2304×1296(3 MP), 1920×1080(1080p); 25/30fps @ 1280×1024
(SXGA); 25/30fps @ 1280×960 (1.3 MP), 1280×720 (720p),
704×576/704×480 (D1), 352×288/352×240 (CIF)
Bit Rate (H.264) 32 Kbps – 10 Mbps
Local Storage microSD, 128 GB max.
Network
Ethernet RJ-45 (10/100Base-T)
Supported Protocols
IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP,
NTP, DHCP, DNS, PPPoE, DDNS, FTP, IP Filter, QoS, SSL, SNMP, Bonjour,
802.1X
Compatibility ONVIF Profile S, CGI
