HCE80(R) / HCC80(R) Mounting and operation
27
Appendix
Navigation and function overview
Function Press button
Status LED
Zone LED Exit mode
Normal mode Lights up green
= Valve open
LED off = Valve closed
Binding
> 2 s
Lights up yellow Flashing 4min after last action
Delete assigned
devices
Mode > 4 s in
binding mode
Lights up yellow Zone LED extinguishes 4min after last action
Device display
> 2 s
Flashing yellow Red = Room actual value
Green = Room
setpoint value
Yellow = Room actual
value/room setpoint value
Automatically after 60s
or
Press other button
Cooling mode
Mode > 4 s
Press the button
in order to activate/
de-activate the
cooling mode
Green = Cooling
mode active
Red = Cooling
mode inactive
Red = Cooling active
and cooling contact
open (Cl. 3 and 4)
Green = Cooling active
and cooling contact
closed (Cl. 3 and 4)
Automatically after 60s
or
Press the Mode button
Send test signal
Keep and Mode
pressed for 4 s
Flashing green Light up red when the
test signal is sent
Automatically after
10minutes
or
Press other button
Receive test signal Flashing green Signal strength of the
assigned device is
indicated by flashing of the
respective green zone LED:
1x = Signal sufficient
5x = Signal strong
10s after last
received test signal
Communica-
tion error
LED lights up red
Flashing red = Room
actual value error
Flashing green = Room
setpoint value error
Flashing yellow = Room
actual value/room
setpoint value error
When error has
been eliminated
Antenna error
LED flashes red
When error has
been eliminated
Reset all settings
Keep and Mode
pressed for 10 s
Flashing yellow Release button
