Document 800-04763 Rev B 37
08/09
Setting the Camera Image Properties
The table below explains the options on the VIEWING menu.
>FLIP Select either:
<ON> to reverse the image horizontally on the video monitor, or
<OFF> (default)
> ID DISPLAY. Select ON to open the CAMERA ID SETUP screen where you
can add a CAMERA ID (title) of up to 8 characters.
Move the cursor (>) to CAMERA ID, then press . The first
character appears. Press
!, or # to change the character, then
press to move to the next character.
When you are satisfied, press
$, or% and move the cursor to
another item.
>ID POSITION Select where you want the Camera ID to appear on the monitor
screen Select from the list:
<UP-LEFT>, <UP-CENTER>, <UP-RIGHT>, <DOWN-
LEFT>, <DOWN-RIGHT>
>SHARPNESS Select the level of sharpness of the image. Choices are:
<NORMAL> (default)
<SHARP>
<SOFT>
>BRIGHTNESS While observing the video monitor, move the cursor to adjust the
overall brightness level, from 80 to 130 (110 is the default).
VIEWING
FLIP OFF
ID DISPLAY <OFF>
SHARPNESS NORMAL
BRIGHTNESS 110 80 130
RESOLUTION NORMAL
COLOR ADJ. 0 -8 8
PREVIOUS PAGE .
&
&
>
CAMERA ID SETUP
CAMERA ID
ID POSITION UP-LEFT
PREVIOUS PAGE .
➀
➀
