<CUSTOM> Opens the CUSTOM screen where you can adjust the limits of the wide
dynamic range by moving the cursor.
Observe the results on the video monitor for the best results.
>WDR LIMIT Adjust the dynamic range to change the camera’s light optimization.
Reduce the level to lower the dynamic range. Adjust the slider from 0 to 36
(default is 20).
<AES> The AES (Automatic Electronic Shutter) feature compensates for
excessive light levels by automatically adjusting the shutter speed of the
camera. Select from:
HIGHLIGHTS for optimum exposure of bright areas of the scene.
SHADOWS for optimum exposure of dark areas of the scene.
WDR Preset Area of Interest WDR Exposure
INDOOR Full scene Wide Highlights
LOADING DOCK Center scene Wide Highlights
GAMING Full scene spot glare Medium Highlights
LICENSE PLATE Full scene spot glare Medium Shadows
OUTDOOR Full scene Ultrawide Highlights
ATM Center scene Ultrawide Shadows
LOBBY Center scene Wide Shadows
CUSTOM
WDR LIMIT 36 0 36
AES SHADOWS
PREVIOUS PAGE .
>
&
To Next Page
