HW1000i / HW2000i Inverter Generator Owner’s Manual www.honeywellgenerators.com 33
Wiring Diagrams
Wiring Diagrams
HW2000i Model
GENERATOR
CONTROL PANEL
GROUND
TERMINAL
STEEL
BASE
primary
#16 black
white
secondary
oil
alert
indicator
light
overload
indicator
light
output
indicator
light
ENGINE
oil alert
sensor
spark
plug
step motor /
fuel control
ignition
coil
M
run / stop
switch
ALTERNATOR
ENGINE BLOCK
#14 black
Duplex 5-20R
#16 yellow / green
AC breaker
20A
G
G
W
W
X
X
efficiency
mode
switch
INVERTER
