BOLT AND FASTENER TORQUE INFORMATION
3-2 www.honeywellgenerators.com Honeywell Portable Generator Service Manual
3.1 BOLT AND FASTENER TORQUE INFORMATION
Component-Specific Fastener Fastener Size
Torque Values
N•m lb. ft. kg-m
Cylinder Head Bolt 10×1.25×80 mm 45 - 50 33.2 - 36.9 4.6 - 5.1
Pivot Bolt 8x1.25 mm 12 - 16 8.9 - 11.8 1.2 - 1.6
Pivot Adjusting Nut 6x0.75 mm 28 - 32 20.7 - 23.6 2.9 - 3.3
Crankcase Cover Bolt 8×1.25×40 mm 27 - 30 19.9 - 22.1 2.8 - 3.1
Connecting Rod Bolt 8×1.25 mm 14 - 16 10.3 - 11.8 1.4 - 1.6
Air Cleaner Wing Nut 6×1.0 mm 2 - 4 1.5 - 3.0 .2 - .4
Muffler Mounting Bolt 8×1.25 mm 27 - 30 19.9 - 22.1 2.8 - 3.1
Oil Drain Bolt 12×1.5 mm 30 - 35 22.1 - 25.8 3.1 - 3.6
Fuel Tank Mounting Bolt 6×1.0 mm 8 - 12 5.9 - 8.9 .8 - 1.2
Fuel Valve Joint Nut 10×1.25 mm 22 - 26 16.2 - 19.2 2.2 - 2.7
Flywheel Mounting Nut 16×1.5 mm 90 - 100 66.4 - 73.8 9.2 - 10.2
Spark Plug 13/16” 27 - 30 19.9 - 22.1 2.8 - 3.1
Ignition Coil 8 mm 8 - 12 5.9 - 8.9 .8 - 1.2
Starter Solenoid Terminal Nut 6×1.0 mm 5 - 7 3.7 - 5.2 .5 - .7
Standard Torque Values
5 mm bolt, nut 5 - 7 3.7 - 5.2 .5 - .7
6 mm bolt, nut 8 - 12 5.9 - 8.9 .8 - 1.2
8 mm bolt, nut 22 - 28 16.2 - 20.7 2.2 - 2.9
10 mm bolt, nut 24 - 32 17.7 - 23.6 2.4 - 3.3
TABLE 3-2. Torque Values
