IntuVueRDR-7000 Weather Radar Pilot's Guide
D201911000094 Table of Contents
Rev 0, Feb 2020 i
TABLE OF CONTENTS
SECTION 1: INTRODUCTION
RDR-7000 OPERATIONAL ENHANCEMENTS
OPERATIONAL
LIMITATIONS AND CONSIDERATIONS
SECTION 2: SIMPLIFIED OPERATING PROCEDURES
CONFIGURATIONS
ON/OFF
TURN
ON AND TEST
TAKEOFF
AND DEPARTURE
CLIMB
UP TO FL200
CRUISE
ABOVE FL200
DESCENT
AND APPROACH
AVOIDANCE
MANEUVERS
SECTION 3: EXPANDED OPERATING INSTRUCTIONS
TURN ON & SYSTEM SELECTION
AUTOMATIC
RADAR ACTIVATION (WX/PWS QUALIFIERS)
GROUND
OVERRIDE
WEATHER
DETECTION
AUTOMATIC
WEATHER MODES (WX ALL & WX PATH)
TURBULENCE
DETECTION
PREDICTIVE
HAIL AND LIGHTNING
REACT
WEATHER-AHEAD
INDICATION
PREDICTIVE
WINDSHEAR (PWS) DETECTION
WEATHER
ANALYSIS
MANUAL
ALTITUDE WEATHER MODE
MANUAL
AZIMUTH WEATHER MODE
FULL
COVERAGE GROUND MAP MODE
GAIN
CONTROL (GAIN)
SECTION 4: EQUIPMENT DESCRIPTION
UNIT DESCRIPTIONS
ART-7000
ANTENNA RECEIVER TRANSMITTER WITH FLAT PLATE
ANTENNA
CONTROL
PANELS AND DISPLAYS
OPERATING
CONTROLS
