LYNX Touch Installation and Setup Guide
- 33 -
Programming the Control
Program the Communications Module (Continued)
GSM Fault Time (min)
00
19. Select “GSM Fault Time (min)”. Enter the time delay (in minutes) on the keypad.
Options
00-99
GSM Rollover
No
20. If “WiFi and GSM” was selected in step 2, two additional programming fields are
displayed. Select “GSM Rollover”, the system toggles between “Yes” and “No”.
GSM 24 Hour Test
No
21. Select “GSM 24 Hour Test”, the system toggles between “Yes” and “No”.
22. If “GSM” was selected in step 2, select “Save” and then select “OK” when the
“Programming Done” screen appears. Proceed to “Diagnostics” section in order to
register the device.
To Next Page
