Honeywell L5210 Series User Manual

LYNX Touch Installation and Setup Guide
- 66 -
System Operation
Event Log
The LYNX Touch Series event log is capable of recording and displaying up to 128 (L5210/L5210CN) or 256
(L7000/L7000CN) system events. The type of events that can be recorded is selectable and is programmed in
the System Type programming field. The event log can be reviewed by entering the Installer Programming
or Master User Programming mode and selecting “Events”. Refer to the LYNX Touch L5210 or L7000 Series
User Manual for additional information. The Events and CID or SIA Codes that are displayed in the Event
Log vary between the LYNX Touch L5210/L5210CN and L7000/L7000CN controls, according to the options
that are programmed. The table below provides definitions of the events/codes that may be displayed by the
panel.
Note: In the unlikely condition that the backup battery becomes fully discharged when AC power is lost, any system activity performed after
the low battery notification will not be saved in the event log. Additionally, the panel will revert to the status condition as before the low
battery notification.
Contact ID
®
& SIA Event Log Codes
CID
Code
Definition
SIA
Code
Definition
110 Alarm, Fire AT/AR AC Trouble/AC Restoral
121 Alarm, Duress BA/BR Burglary Alarm/Burglary Restoral
122 Alarm, Silent CA/CD Automatic Closing/Closing Delinquent
123 Alarm, Audible CI Fail to Close (Log only)
131 Alarm, Perimeter CL Closing Report
132 Alarm, Interior CQ Remote Closing
134 Alarm, Entry/Exit CR Recent Closing
135 Alarm, Day/Night DF/DR Door Forced/Door Restoral
137 Alarm, Tamper EA Exit Alarm
145 Expansion Module Tamper ES/EJ Expansion Device Tamper/Expansion Tamper Restore
146 Silent Burglary ET Expansion Trouble
150 24-Hour Non-Burglary FA Fire Alarm
162 Carbon Monoxide Detected FT/FJ Fire Trouble/Fire Trouble Restore
301 Trouble, AC Loss HA/HR Holdup Alarm/Holdup Restoral
302 Trouble, Low System Battery GA/GR Gas Alarm/Gas Restoral
305 Trouble, System Reset FT/FJ Fire Trouble/Fire Trouble Restore
316 System Tamper* LT/LR Phone Line Trouble/Phone Line Restoral
341 Trouble, Case Tamper OA Automatic Opening
344 Trouble, RF Receiver Jam Detect OC Cancel Report
351 Trouble, Telco 1 Fault OP Opening Report
353 Trouble, Long Range Radio Transmitter Fault OQ Remote Opening
373 Trouble, Fire Trouble PA Panic Alarm
374 Trouble, Exit Error Alarm RP Automatic Test
380 Trouble, Sensor RX Manual Test
381 Trouble, Loss of Supervision RF TA/TH Tamper Alarm/Tamper Alarm Restore
383 Trouble, Sensor Tamper TJ Tamper Trouble Restore
384 RF Low Battery TS/TE Test Start/Test End
401 Open/Close by User TT Tamper Trouble
403 Open/Close Automatic UA Untyped Zone Alarm
406 Cancel UB/UU Untyped Zone Bypass/Untyped Zone Unbypass
407 Remote Arm/Disarm UT/UJ Untyped Zone Trouble/Restore
408 Quick Arm XG/XH RF Interference/RF Interference Restore
441 Armed Stay XT/XR Transmitter Battery Trouble/Transmitter Battery Restoral
455 Auto-Arm Failed YT/YR System Battery Trouble/System Battery Restoral
459
Recent Close
570
Zone/Sensor Bypass
601
Manual Trigger Test Report
602 Periodic Test Report
606 Listen-in to follow
607 Walk Test
623 Event 90% Full
627 Program Mode Entry (Logged in Event Log Only)
628 Program Mode Exit (Logged in Event Log Only)
*If APL is enabled, AlarmNet will generate a special comm. fail
message (E316) if it does not hear from a unit within 15 minutes
after a delayed alarm is delivered. This message is meant to alert
the Central Station that the system has been tampered with and
may have been compromised.
654 System Inactivity
655 Reset Master Code (Logged in Event Log Only)
759 Resident Monitor Zone Response
760 Resident Response Zone Response
761 General Monitor Zone Response
762 General Response Zone Response
