Zone Programming Default Values
Zone Assignment/Alarm Response Types for Values 3 and 4
Zone
Number
Loop
Number
Device Type Response Type
Alarm
Report
Chime Supervision
Arm
Night
Zone Descriptor
1 --- New Not Used Yes Disabled End of Line n/a n/a
2 2 Door Entry Exit 1 Yes Standard Supervised n/a Front
3 2 Door Entry Exit 1 Yes Standard Supervised n/a Back
4 2 Window Perimeter Yes Disabled Supervised n/a n/a
5 2 Window Perimeter Yes Disabled Supervised n/a n/a
6 2 Window Perimeter Yes Disabled Supervised n/a n/a
7 2 Window Perimeter Yes Disabled Supervised n/a n/a
8 1 Motion Sensor Interior With Delay Yes Disabled Supervised No n/a
9 1 Smoke Detector Fire No Verification Yes Disabled Supervised n/a n/a
46 1 New Not Used No Standard Supervised n/a Main
47 1 New Not Used No Standard Supervised n/a Main
48 1 New Not Used No Standard Supervised n/a Main
140 3 4 Button Arm Away Yes Disabled Button n/a n/a
141 2 4 Button Disarm Yes Disabled Button n/a n/a
142 4 4 Button No Response Yes Disabled Button n/a n/a
143 1 4 Button No Response No Disabled Button n/a n/a
144 3 4 Button Arm Away Yes Disabled Button n/a n/a
145 2 4 Button Disarm Yes Disabled Button n/a n/a
146 4 4 Button No Response Yes Disabled Button n/a n/a
147 1 4 Button No Response No Disabled Button n/a n/a
180 --- Temperature Monitor Yes Disabled High Temp n/a n/a
181 --- Temperature Monitor Yes Disabled Low Temp n/a n/a
182 --- Temperature Monitor Yes Disabled High Temp n/a n/a
183 --- Temperature Monitor Yes Disabled Low Temp n/a n/a
184 --- Temperature Monitor Yes Disabled High Temp n/a n/a
185 --- Temperature Monitor Yes Disabled Low Temp n/a n/a
95 --- Fire Fire No Verification Yes Disabled Panic Trigger n/a n/a
96 --- Medical Not Used Yes Disabled Panic Trigger n/a n/a
99 --- Police 24-Hour Silent Yes Disabled Panic Trigger n/a n/a
Zone Response Type Matrix
Device Type
Response Type
Entry Exit 1 Entry Exit 2 Perimeter Resident Monitor Resident Response General Monitor General Response Day/Night Interior Follower Interior With Delay
Fire No Verification
Fire With Verification Carbon Monoxide 24 Hour Auxiliary 24 Hour Audible 24 Hour Silent Monitor Not Used Arm Stay Arm Away
Disarm
No Response Silent Burglary Garage Garage Monitor Trouble
Door x x x x x x x
Window x x x x x x x
Motion Sensor x x x x x x x x
Glass Break x x x x x
Smoke Detector x x
Heat Sensor x
Carbon Monoxide Detector x
Temperature x x x x x x
Flood x x
Environmental x x x x x x
Medical x x x
Fire x x
Police x x x x
Garage Door x x
Other x x x x x x x x x x x x x x x x x x x x x x x x x x
