Appendix A — Printer Specifications
68 MP Nova Mark II User Guide
MP Nova4 DT & TT
Technical Specifications: MP Nova4 DT & TT
Dimensions (H x W x L) DT: 150 x 232 x 360 mm (6” x 9-1/8” x 14-1/8”)
TT: 210 x 250 x 360 mm (8-1/4” x 9-1/2” x 14-1/8”)
Weight DT: 5.8 kg (12 lbs), TT: 7.2 kg (15 lbs)
Power pack 100/240 VAC 50-60 Hz, 325 VA
Printer technology Direct thermal and thermal transfer
Printing width 104 mm (4-1/8”)
Printing speed DT: 80 – 250 mm/second, TT: 80 – 250 mm/second
Printing resolution 203 dpi/300 dpi
Media specifications Width: 40 mm – 115 mm (1-1/2” – 4-1/2”)
Length: 10 mm (3/8”) – unlimited
Thickness: 58 µm – 180 µm
Media types Roll or fan-folded paper
External diameter of roll: maximum 215 mm (8-1/2”)
Inner core of roll: minimum 37 mm (1-1/2”) in diameter
Ink ribbon, TT Maximum width of roll: 110 mm (4-1/3”)
Inner core diameter of roll: 25 mm (1”)
Maximum length: 300 m (328 yards)
CSI/CSO maximum outer diameter of ribbon roll: 300 mm (11-4/5”)
Connections 1 x RS-232 port (up to 115 kBps)
USB port
Ethernet port [TCP/IP (LPD)]
Typefaces 10 scalable typefaces
13 scalable, emulated typefaces
Supports true type typefaces
Bar codes Most common bar codes including two-dimensional.
Examples: EAN128, Interleaved 2 of 5, Code 39 and PDF417
Graphics Supports several file types
Settings program Internal program using Web browser or NETira CT
Counters Two internal counters
Memory 32 Mb standard RAM
Time and date Internal clock, real-time
Printhead diagnostic PHD (Printhead Diagnostic)
