UL294 Performance Level
Cable
Use industry-standard cables that meet the following specifica-
tions:
Destructive Attack: I
Line Security: I
Endurance: IV
Standby Power: I
Cable
Specifications
Description AWG
Maximum
Distance:
Feet (Meters)
Readers
8 Conductor,
Shielded.
(CAT 5E/
6E FTP)
22-24 OSDP = 150 m
(500 Ft)
Depending on
minimum voltage
input of the reader
Alarm Input
Twisted Pair,
Shielded.
(CAT 5E/
6E FTP)
22-24 300 m (1000 Ft)
Relay Outputs
Twisted Pair,
Shielded.
(CAT 5E/
6E FTP)
22-24 300 m (1000 Ft)
