51
Honeywell Access Sy
stems
135 W
.
Forest Hill Avenue
Oak Creek, WI 53154
United States
800-323-4576
414-766-1798 F
ax
ww
w.
honey
wellaccess.com
Specifications subject to change
without notice.
© Honeywell.
All rights reserv
ed.
Document #: 800-26169_
Rev E
Date: September
2020
51
Table of Contents
MPA1C1
1
Installing the MPA1C1 Panels
3
Introduction
4
Panel Components and Descriptions
6
MPA1C1 door with single-reader and door strike
8
MPA1C1 door with two-readers and door strike
8
Recommended backup power source
12
Power Source
12
Power Backup
12
PoE Switch or PoE inserter
12
UPS (Unbreakable Power Supply)
12
External 12V Power
12
7Ah sealed lead-acid battery
12
Download and Install App
14
Mounting and Installing Options
15
MPA1ENCP Plastic Enclosure Installation
16
The Inner Base
22
Wiring an Access Control Door Strike
28
Wiring an Access Control Magnetic Lock
29
Non-supervised input Terminal Blocks
31
Supervised and non-supervised input wiring
32
Commission the MPA1C1
34
Step 1. Check all wiring.
34
System Configuration
35
Ethernet Connection for standalone web mode
35
Ethernet Virtual Loop (EVL) with all panels on common IP Subnet
36
Ethernet Virtual Loop - network dedicated to Access Control
37
Ethernet Connection with Virtual Loop - Multiple Locations
38
Hardware Specifications
40
Power consumptions
42
Mechanical dimensions
43
Environment
43
Cable
44
Basic Standalone Operation
45
Step 1. Present a card to a reader.
45
Step 1. Activate the door egress input (REX).
45
Troubleshooting
46
Troubleshooting Problems and Solutions
46
Technical Support
50
