Introduction
Page 2 MDE-4636C Honeywell® MS3780 Fusion Scanner Setup/Service Instructions · July 2021
Connections Diagrams
Figure 1: G-SITE
System Connections Diagram
Hand-held Scanner
(Q12651-21)
Power Supply (Q12651-20)
Gender Mender
(Q13180-35 or 35B)
Work Area Cable
(Q13850-06)
G-SITE System
Scanner Port
