Honeywell MS3780 Fusion Setup/Service Instructions

Programming Information
Page 8 MDE-4636C Honeywell® MS3780 Fusion Scanner Setup/Service Instructions · July 2021
Programming the Scanner
To program the scanner, proceed as follows:
1 Ensure that the scanner is connected to the G-SITE or Passport system.
2 For the G-SITE systems, determine if the Back Office Pricebook software accepts/requires a 
11-digit Expanded UPC recognition and/or Convert UPC-A
to EAN-13 recognition.
Notes: 1) If Expanded UPC recognition is not required, do not scan “Sheet 16” on
page 35; 
if Convert UPC-A to EAN-13 recognition is not required, do not scan “Sheet 16” on
page 35.
2) Envoy BOS requires Expanded UPC and Convert UPC-A to EAN-13 when
interfaci
ng with G-SITE systems.
3 Scan the barcodes on “Sheet 1” on page 20 to “Sheet 18” on page 37 in order (if the scanner is
connected to a Passport system, skip “Sheet 11” on page 30). After you scan “Sheet 1” on
page 20 to enter the configuration mode, the scanner will beep three times and the L
ight
Emitting Diode (LED) will flash.
Sheet Function Sheet Function
1 Enter/Exit Configuration Mode 11* 2400 Baud Rate
2 Recall Defaults 12 1 Stop Bit
3 Disable Code 128 13**** Enable UPC Prefix ID
4 Disable Code 93 14 Disable LF Suffix
5 Disable Codabar 15** Expand UPC-E to 12 Digits
6 • Disable Interleaved 2 of 5 (ITF)
• Enable Interleaved 2 of 5 (ITF)
16*** Convert UPC-A to EAN-13
7 Disable Code 39 17 No Power Save Mode
8 Transmit UPC-A Check Digit 18 Disable CodeGate Out of Stand, Primary Pattern
Active
9 Transmit UPC-E Check Digit 19 Enter/Exit Configuration Mode
10 Even Parity
* Do not use if the scanner is connected to a Passport system. The Passport system requires default 9600 baud rate.
** Use only if Expanded UPC recognition is supported/required.
*** Use only if Convert UPC-A to EAN-13 recognition is sup
ported/required. Not required for Passport systems.
**** Do not use if the scanner is connected to a Passport System running V20.04 o
r later.
4 If Expanded UPC recognition is required by the Back Office software, scan “Sheet 15” on
page 34.
5 If Convert UPC-A to EAN-13 recognition is required by the Back Office software, scan 
“Sheet 16” on page 35.
Note: This option is required for G-SITE systems t
hat interface with Envoy BOS. This option
is not required for Passport systems.
6 Scan “Sheet 18” on page 37 to exit the configuration mode. The scanner will beep three times.
7 For G-SITE systems, cycle the console power before testing the scanner to ensure proper
operation.
~ OR ~
For Passport systems, stop and rest
art the Passport application using the System Maintenance
toolbar to ensure proper operation.

Honeywell MS3780 Fusion Specifications

General

Scan speed	1333 sec/page
Wavelength	650 nm
Decoding standards	1D, GS1
Dimensions (WxDxH)	189 x 65 x 73 mm
Standard interfaces	Keyboard wedge
Input voltage	5 V
Certification	FCC Part 15, ICES-003, EN55022 Class B
Product color	Black
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-20 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	195 g
