ID2000 Series Installation & Commissioning Manual
Appendix 1
A1 - 4
997-433-000-5, Issue 5
May 2010
1.1.6 Printer Faults
Printer Fault
Internal printer only. This fault may be an indication of a
paper jam or malfunction, no paper, or the printer
disconnected.
Note: The printer operation is only monitored if the printer
was functional at the last power-on.
1.1.7 Other Hardware Faults
a. Fault 47 - CPU/Display hardware fault
Communications fault between the CPU and the display.
Change the CPU PCB assembly (PN: 020-569) and/or
the Display PCB/Membrane Keypad (PN: 020-491-XXX).
b. Panel Key Stuck
Change the Display PCB/Membrane Keypad
(PN: 020-491-XXX).
c. Fault 48 - Base PCB/Expansion h/w fault
Change the Base PCB (PN: 020-568) or Extension Chassis
with Display Module Kit (PN: 020-469-XXX).
If an E-LIB PCB (PN: 124-292 is fitted in any of the LIB
connectors, the following warning is displayed:
‘Incompatible LIB card Installed’
Fit a LIB PCB (PN: 124-323) instead.
Note: When using the off-line DOS configuration tool it
is possible to select an E-LIB. In this case when
the configuration is downloaded to the panel an
‘ELIB card missing or fault’ message is displayed.
If an E-LIB PCB is fitted, the ‘Incompatible LIB card
Installed’ warning is also displayed. Make sure that
no E-LIBs are configured to avoid this E-LIB
incompatibility situation occurring.
d. Aux. Output 1 Fault
Aux. Output 2 Fault
Replace the fuse (F5 or F6 respectively) on the Base PCB.
e. Fault 71 - Config. needs Expansion Card
Missing PCB - panel is configured for 80 zones. Fit
Extension Chassis with Display Module Kit (PN: 020-469-XXX).
f. Fault 72 - Config. needs RS485 Card
Missing PCB - panel is configured for network but no RS485
PCB is present. Fit Isolated RS485 Module Kit (PN: 020-479).
g. Fault 73 - Config. needs RS232 Card
Missing PCB - panel is configured for 3rd party protocol
but no RS232 PCB is present (does not apply to other
modes of the port). Fit Isolated RS232 Module Kit
(PN: 020-478) or change configuration.
h. Fault 74 - RS232\RS485\PRINTER Card displaced
An attempt has been made to remove one of these items
while the panel is powered up. Remove power before
proceeding.
To Next Page
